C Introduction to R

This section provides a collection of self-explainable snippets of the programming language R (R Core Team 2017) that show the very basics of the language. It is not meant to be an exhaustive introduction to R, but rather a reminder/panoramic of a collection of basic functions and methods.

In the following, # denotes comments to the code and ## outputs of the code.

Simple computations

# The console can act as a simple calculator
1.0 + 1.1
## [1] 2.1
2 * 2
## [1] 4
3/2
## [1] 1.5
2^3
## [1] 8
1/0
## [1] Inf
0/0
## [1] NaN

# Use ";" for performing several operations in the same line
(1 + 3) * 2 - 1; 3 + 2
## [1] 7
## [1] 5

# Elemental mathematical functions
sqrt(2); 2^0.5
## [1] 1.414214
## [1] 1.414214
exp(1)
## [1] 2.718282
log(10) # Neperian logarithm
## [1] 2.302585
log10(10); log2(10) # Logs in base 10 and 2
## [1] 1
## [1] 3.321928
sin(pi); cos(0); asin(0)
## [1] 1.224647e-16
## [1] 1
## [1] 0
tan(pi/3)
## [1] 1.732051
sqrt(-1)
## [1] NaN
# Remember to close the parenthesis
1 +
(1 + 3
## Error: <text>:4:0: unexpected end of input
## 2: 1 +
## 3: (1 + 3
##   ^

Exercise C.1 Compute:

  • \(\frac{e^{2}+\sin(2)}{\cos^{-1}\left(\tfrac{1}{2}\right)+2}.\) Answer: 2.723274.
  • \(\sqrt{3^{2.5}+\log(10)}.\) Answer: 4.22978.
  • \((2^{0.93}-\log_2(3 + \sqrt{2+\sin(1)}))10^{\tan(1/3))}\sqrt{3^{2.5}+\log(10)}.\) Answer: -3.032108.

Variables and assignment

# Any operation that you perform in R can be stored in a variable (or object)
# with the assignment operator "<-"
x <- 1

# To see the value of a variable, simply type it
x
## [1] 1

# A variable can be overwritten
x <- 1 + 1

# Now the value of x is 2 and not 1, as before
x
## [1] 2

# Careful with capitalization
X
## Error in eval(expr, envir, enclos): object 'X' not found

# Different
X <- 3
x; X
## [1] 2
## [1] 3

# The variables are stored in your workspace (a .RData file)
# A handy tip to see what variables are in the workspace
ls()
## [1] "x" "X"
# Now you know which variables can be accessed!

# Remove variables
rm(X)
X
## Error in eval(expr, envir, enclos): object 'X' not found

Exercise C.2 Do the following:

  • Store \(-123\) in the variable y.
  • Store the log of the square of y in z.
  • Store \(\frac{y-z}{y+z^2}\) in y and remove z.
  • Output the value of y. Answer: 4.366734.

Vectors

# These are vectors - arrays of numbers
# We combine numbers with the function "c"
c(1, 3)
## [1] 1 3
c(1.5, 0, 5, -3.4)
## [1]  1.5  0.0  5.0 -3.4

# A handy way of creating integer sequences is the operator ":"
# Sequence from 1 to 5
1:5
## [1] 1 2 3 4 5

# Storing some vectors
myData <- c(1, 2)
myData2 <- c(-4.12, 0, 1.1, 1, 3, 4)
myData
## [1] 1 2
myData2
## [1] -4.12  0.00  1.10  1.00  3.00  4.00

# Entrywise operations
myData + 1
## [1] 2 3
myData^2
## [1] 1 4

# If you want to access a position of a vector, use [position]
myData[1]
## [1] 1
myData2[6]
## [1] 4

# You also can change elements
myData[1] <- 0
myData
## [1] 0 2

# Think on what you want to access...
myData2[7]
## [1] NA
myData2[0]
## numeric(0)

# If you want to access all the elements except a position, use [-position]
myData2[-1]
## [1] 0.0 1.1 1.0 3.0 4.0
myData2[-2]
## [1] -4.12  1.10  1.00  3.00  4.00

# Also with vectors as indexes
myData2[1:2]
## [1] -4.12  0.00
myData2[myData]
## [1] 0

# And also
myData2[-c(1, 2)]
## [1] 1.1 1.0 3.0 4.0

# But do not mix positive and negative indexes!
myData2[c(-1, 2)]
## Error in myData2[c(-1, 2)]: only 0's may be mixed with negative subscripts

# Remove the first element
myData2 <- myData2[-1]

Exercise C.3 Do the following:

  • Create the vector \(x=(1, 7, 3, 4).\)
  • Create the vector \(y=(100, 99, 98, ..., 2, 1).\)
  • Create the vector \(z=c(4, 8, 16, 32, 96).\)
  • Compute \(x_2+y_4\) and \(\cos(x_3) + \sin(x_2) e^{-y_2}.\) Answers: 104 and -0.9899925.
  • Set \(x_{2}=0\) and \(y_{2}=-1.\) Recompute the previous expressions. Answers: 97 and 2.785875.
  • Index \(y\) by \(x+1\) and store it as z. What is the output? Answer: z is c(-1, 100, 97, 96).

Some functions

# Functions take arguments between parenthesis and transform them into an output
sum(myData)
## [1] 2
prod(myData)
## [1] 0

# Summary of an object
summary(myData)
##    Min. 1st Qu.  Median    Mean 3rd Qu.    Max.
##     0.0     0.5     1.0     1.0     1.5     2.0

# Length of the vector
length(myData)
## [1] 2

# Mean, standard deviation, variance, covariance, correlation
mean(myData)
## [1] 1
var(myData)
## [1] 2
cov(myData, myData^2)
## [1] 4
cor(myData, myData * 2)
## [1] 1
quantile(myData)
##   0%  25%  50%  75% 100%
##  0.0  0.5  1.0  1.5  2.0

# Maximum and minimum of vectors
min(myData)
## [1] 0
which.min(myData)
## [1] 1

# Usually the functions have several arguments, which are set by "argument = value"
# In this case, the second argument is a logical flag to indicate the kind of sorting
sort(myData) # If nothing is specified, decreasing = FALSE is assumed
## [1] 0 2
sort(myData, decreasing = TRUE)
## [1] 2 0

# Do not know what are the arguments of a function? Use args and help!
args(mean)
## function (x, ...)
## NULL
?mean

Exercise C.4 Do the following:

  • Compute the mean, median and variance of \(y.\) Answers: 49.5, 49.5, 843.6869.
  • Do the same for \(y+1.\) What are the differences?
  • What is the maximum of \(y\)? Where is it placed?
  • Sort \(y\) increasingly and obtain the 5th and 76th positions. Answer: c(4,75).
  • Compute the covariance between \(y\) and \(y.\) Compute the variance of \(y.\) Why do you get the same result?

Matrices, data frames, and lists

# A matrix is an array of vectors
A <- matrix(1:4, nrow = 2, ncol = 2)
A
##      [,1] [,2]
## [1,]    1    3
## [2,]    2    4

# Another matrix
B <- matrix(1, nrow = 2, ncol = 2, byrow = TRUE)
B
##      [,1] [,2]
## [1,]    1    1
## [2,]    1    1

# Matrix is a vector with dimension attributes
dim(A)
## [1] 2 2

# Binding by rows or columns
rbind(1:3, 4:6)
##      [,1] [,2] [,3]
## [1,]    1    2    3
## [2,]    4    5    6
cbind(1:3, 4:6)
##      [,1] [,2]
## [1,]    1    4
## [2,]    2    5
## [3,]    3    6

# Entrywise operations
A + 1
##      [,1] [,2]
## [1,]    2    4
## [2,]    3    5
A * B
##      [,1] [,2]
## [1,]    1    3
## [2,]    2    4

# Accessing elements
A[2, 1] # Element (2, 1)
## [1] 2
A[1, ] # First row - this is a vector
## [1] 1 3
A[, 2] # First column - this is a vector
## [1] 3 4

# Obtain rows and columns as matrices (and not as vectors)
A[1, , drop = FALSE]
##      [,1] [,2]
## [1,]    1    3
A[, 2, drop = FALSE]
##      [,1]
## [1,]    3
## [2,]    4

# Matrix transpose
t(A)
##      [,1] [,2]
## [1,]    1    2
## [2,]    3    4

# Matrix multiplication
A %*% B
##      [,1] [,2]
## [1,]    4    4
## [2,]    6    6
A %*% B[, 1]
##      [,1]
## [1,]    4
## [2,]    6
A %*% B[1, ]
##      [,1]
## [1,]    4
## [2,]    6

# Care is needed
A %*% B[1, , drop = FALSE] # Incompatible product
## Error in A %*% B[1, , drop = FALSE]: non-conformable arguments

# Compute inverses with "solve"
solve(A) %*% A
##      [,1] [,2]
## [1,]    1    0
## [2,]    0    1

# A data frame is a matrix with column names
# Useful when you have multiple variables
myDf <- data.frame(var1 = 1:2, var2 = 3:4)
myDf
##   var1 var2
## 1    1    3
## 2    2    4

# You can change names
names(myDf) <- c("newname1", "newname2")
myDf
##   newname1 newname2
## 1        1        3
## 2        2        4

# The nice thing is that you can access variables by its name with
# the "$" operator
myDf$newname1
## [1] 1 2

# And create new variables also (it has to be of the same
# length as the rest of variables)
myDf$myNewVariable <- c(0, 1)
myDf
##   newname1 newname2 myNewVariable
## 1        1        3             0
## 2        2        4             1

# A list is a collection of arbitrary variables
myList <- list(myData = myData, A = A, myDf = myDf)

# Access elements by names
myList$myData
## [1] 0 2
myList$A
##      [,1] [,2]
## [1,]    1    3
## [2,]    2    4
myList$myDf
##   newname1 newname2 myNewVariable
## 1        1        3             0
## 2        2        4             1

# Reveal the structure of an object
str(myList)
## List of 3
##  $ myData: num [1:2] 0 2
##  $ A     : int [1:2, 1:2] 1 2 3 4
##  $ myDf  :'data.frame':  2 obs. of  3 variables:
##   ..$ newname1     : int [1:2] 1 2
##   ..$ newname2     : int [1:2] 3 4
##   ..$ myNewVariable: num [1:2] 0 1
str(myDf)
## 'data.frame':    2 obs. of  3 variables:
##  $ newname1     : int  1 2
##  $ newname2     : int  3 4
##  $ myNewVariable: num  0 1

# A less lengthy output
names(myList)
## [1] "myData" "A"      "myDf"

Exercise C.5 Do the following:

  • Create a matrix called M with rows given by y[3:5], y[3:5]^2 and log(y[3:5]).

  • Create a data frame called myDataFrame with column names “y,” “y2” and “logy” containing the vectors y[3:5], y[3:5]^2 and log(y[3:5]), respectively.

  • Create a list, called l, with entries for x and M. Access the elements by their names.

  • Compute the squares of myDataFrame and save the result as myDataFrame2.

  • Compute the log of the sum of myDataFrame and myDataFrame2. Answer:

        ##         y       y2     logy
    ## 1 9.180087 18.33997 3.242862
    ## 2 9.159678 18.29895 3.238784
    ## 3 9.139059 18.25750 3.234656

More on data frames

# Let's begin importing the iris dataset
data(iris, package = "datasets")

# "names" gives you the variables in the data frame
names(iris)
## [1] "Sepal.Length" "Sepal.Width"  "Petal.Length" "Petal.Width"  "Species"

# The beginning of the data
head(iris)
##   Sepal.Length Sepal.Width Petal.Length Petal.Width Species
## 1          5.1         3.5          1.4         0.2  setosa
## 2          4.9         3.0          1.4         0.2  setosa
## 3          4.7         3.2          1.3         0.2  setosa
## 4          4.6         3.1          1.5         0.2  setosa
## 5          5.0         3.6          1.4         0.2  setosa
## 6          5.4         3.9          1.7         0.4  setosa

# So we can access variables by "$" or as in a matrix
iris$Sepal.Length[1:10]
##  [1] 5.1 4.9 4.7 4.6 5.0 5.4 4.6 5.0 4.4 4.9
iris[1:10, 1]
##  [1] 5.1 4.9 4.7 4.6 5.0 5.4 4.6 5.0 4.4 4.9
iris[3, 1]
## [1] 4.7

# Information on the dimension of the data frame
dim(iris)
## [1] 150   5

# "str" gives the structure of any object in R
str(iris)
## 'data.frame':    150 obs. of  5 variables:
##  $ Sepal.Length: num  5.1 4.9 4.7 4.6 5 5.4 4.6 5 4.4 4.9 ...
##  $ Sepal.Width : num  3.5 3 3.2 3.1 3.6 3.9 3.4 3.4 2.9 3.1 ...
##  $ Petal.Length: num  1.4 1.4 1.3 1.5 1.4 1.7 1.4 1.5 1.4 1.5 ...
##  $ Petal.Width : num  0.2 0.2 0.2 0.2 0.2 0.4 0.3 0.2 0.2 0.1 ...
##  $ Species     : Factor w/ 3 levels "setosa","versicolor",..: 1 1 1 1 1 1 1 1 1 1 ...

# Recall the species variable: it is a categorical variable (or factor),
# not a numeric variable
iris$Species[1:10]
##  [1] setosa setosa setosa setosa setosa setosa setosa setosa setosa setosa
## Levels: setosa versicolor virginica

# Factors can only take certain values
levels(iris$Species)
## [1] "setosa"     "versicolor" "virginica"

# If a file contains a variable with character strings as observations (either
# encapsulated by quotation marks or not), the variable will become a factor
# when imported into R

Exercise C.6 Do the following:

  • Load the faithful dataset into R.
  • Get the dimensions of faithful and show beginning of the data.
  • Retrieve the fifth observation of eruptions in two different ways.
  • Obtain a summary of waiting.

Vector-related functions

# The function "seq" creates sequences of numbers equally separated
seq(0, 1, by = 0.1)
##  [1] 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
seq(0, 1, length.out = 5)
## [1] 0.00 0.25 0.50 0.75 1.00

# You can short the latter argument
seq(0, 1, l = 5)
## [1] 0.00 0.25 0.50 0.75 1.00

# Repeat number
rep(0, 5)
## [1] 0 0 0 0 0

# Reverse a vector
myVec <- c(1:5, -1:3)
rev(myVec)
##  [1]  3  2  1  0 -1  5  4  3  2  1

# Another way
myVec[length(myVec):1]
##  [1]  3  2  1  0 -1  5  4  3  2  1

# Count repetitions in your data
table(iris$Sepal.Length)
##
## 4.3 4.4 4.5 4.6 4.7 4.8 4.9   5 5.1 5.2 5.3 5.4 5.5 5.6 5.7 5.8 5.9   6 6.1 6.2 6.3 6.4 6.5 6.6 6.7 6.8 6.9   7 7.1 7.2
##   1   3   1   4   2   5   6  10   9   4   1   6   7   6   8   7   3   6   6   4   9   7   5   2   8   3   4   1   1   3
## 7.3 7.4 7.6 7.7 7.9
##   1   1   1   4   1
table(iris$Species)
##
##     setosa versicolor  virginica
##         50         50         50

Exercise C.7 Do the following:

  • Create the vector \(x=(0.3, 0.6, 0.9, 1.2).\)
  • Create a vector of length 100 ranging from \(0\) to \(1\) with entries equally separated.
  • Compute the amount of zeros and ones in x <- c(0, 0, 1, 0, 1, 0, 0, 1, 0, 1, 0). Check that they are the same as in rev(x).
  • Compute the vector \((0.1, 1.1, 2.1, ..., 100.1)\) in four different ways using seq and rev. Do the same but using : instead of seq. (Hint: add 0.1)

Logical conditions and subsetting

# Relational operators: x < y, x > y, x <= y, x >= y, x == y, x!= y
# They return TRUE or FALSE

# Smaller than
0 < 1
## [1] TRUE

# Greater than
1 > 1
## [1] FALSE

# Greater or equal to
1 >= 1 # Remember: ">="" and not "=>"" !
## [1] TRUE

# Smaller or equal to
2 <= 1 # Remember: "<="" and not "=<"" !
## [1] FALSE

# Equal
1 == 1 # Tests equality. Remember: "=="" and not "="" !
## [1] TRUE

# Unequal
1 != 0 # Tests inequality
## [1] TRUE

# TRUE is encoded as 1 and FALSE as 0
TRUE + 1
## [1] 2
FALSE + 1
## [1] 1

# In a vector-like fashion
x <- 1:5
y <- c(0, 3, 1, 5, 2)
x < y
## [1] FALSE  TRUE FALSE  TRUE FALSE
x == y
## [1] FALSE FALSE FALSE FALSE FALSE
x != y
## [1] TRUE TRUE TRUE TRUE TRUE

# Subsetting of vectors
x
## [1] 1 2 3 4 5
x[x >= 2]
## [1] 2 3 4 5
x[x < 3]
## [1] 1 2

# Easy way of work with parts of the data
data <- data.frame(x = c(0, 1, 3, 3, 0), y = 1:5)
data
##   x y
## 1 0 1
## 2 1 2
## 3 3 3
## 4 3 4
## 5 0 5

# Data such that x is zero
data0 <- data[data$x == 0, ]
data0
##   x y
## 1 0 1
## 5 0 5

# Data such that x is larger than 2
data2 <- data[data$x > 2, ]
data2
##   x y
## 3 3 3
## 4 3 4

# In an example
iris$Sepal.Width[iris$Sepal.Width > 3]
##  [1] 3.5 3.2 3.1 3.6 3.9 3.4 3.4 3.1 3.7 3.4 4.0 4.4 3.9 3.5 3.8 3.8 3.4 3.7 3.6 3.3 3.4 3.4 3.5 3.4 3.2 3.1 3.4 4.1 4.2
## [30] 3.1 3.2 3.5 3.6 3.4 3.5 3.2 3.5 3.8 3.8 3.2 3.7 3.3 3.2 3.2 3.1 3.3 3.1 3.2 3.4 3.1 3.3 3.6 3.2 3.2 3.8 3.2 3.3 3.2
## [59] 3.8 3.4 3.1 3.1 3.1 3.1 3.2 3.3 3.4

# Problem - what happened?
data[x > 2, ]
##   x y
## 3 3 3
## 4 3 4
## 5 0 5

# In an example
summary(iris)
##   Sepal.Length    Sepal.Width     Petal.Length    Petal.Width          Species
##  Min.   :4.300   Min.   :2.000   Min.   :1.000   Min.   :0.100   setosa    :50
##  1st Qu.:5.100   1st Qu.:2.800   1st Qu.:1.600   1st Qu.:0.300   versicolor:50
##  Median :5.800   Median :3.000   Median :4.350   Median :1.300   virginica :50
##  Mean   :5.843   Mean   :3.057   Mean   :3.758   Mean   :1.199
##  3rd Qu.:6.400   3rd Qu.:3.300   3rd Qu.:5.100   3rd Qu.:1.800
##  Max.   :7.900   Max.   :4.400   Max.   :6.900   Max.   :2.500
summary(iris[iris$Sepal.Width > 3, ])
##   Sepal.Length    Sepal.Width     Petal.Length    Petal.Width           Species
##  Min.   :4.400   Min.   :3.100   Min.   :1.000   Min.   :0.1000   setosa    :42
##  1st Qu.:5.000   1st Qu.:3.200   1st Qu.:1.450   1st Qu.:0.2000   versicolor: 8
##  Median :5.400   Median :3.400   Median :1.600   Median :0.4000   virginica :17
##  Mean   :5.684   Mean   :3.434   Mean   :2.934   Mean   :0.9075
##  3rd Qu.:6.400   3rd Qu.:3.600   3rd Qu.:5.000   3rd Qu.:1.8000
##  Max.   :7.900   Max.   :4.400   Max.   :6.700   Max.   :2.5000

# On the factor variable only makes sense == and !=
summary(iris[iris$Species == "setosa", ])
##   Sepal.Length    Sepal.Width     Petal.Length    Petal.Width          Species
##  Min.   :4.300   Min.   :2.300   Min.   :1.000   Min.   :0.100   setosa    :50
##  1st Qu.:4.800   1st Qu.:3.200   1st Qu.:1.400   1st Qu.:0.200   versicolor: 0
##  Median :5.000   Median :3.400   Median :1.500   Median :0.200   virginica : 0
##  Mean   :5.006   Mean   :3.428   Mean   :1.462   Mean   :0.246
##  3rd Qu.:5.200   3rd Qu.:3.675   3rd Qu.:1.575   3rd Qu.:0.300
##  Max.   :5.800   Max.   :4.400   Max.   :1.900   Max.   :0.600

# Subset argument in lm
lm(Sepal.Width ~ Petal.Length, data = iris, subset = Sepal.Width > 3)
##
## Call:
## lm(formula = Sepal.Width ~ Petal.Length, data = iris, subset = Sepal.Width >
##     3)
##
## Coefficients:
##  (Intercept)  Petal.Length
##      3.59439      -0.05455
lm(Sepal.Width ~ Petal.Length, data = iris, subset = iris$Sepal.Width > 3)
##
## Call:
## lm(formula = Sepal.Width ~ Petal.Length, data = iris, subset = iris$Sepal.Width >
##     3)
##
## Coefficients:
##  (Intercept)  Petal.Length
##      3.59439      -0.05455
# Both iris$Sepal.Width and Sepal.Width in subset are fine: data = iris
# tells R to look for Sepal.Width in the iris dataset

# AND operator "&"
TRUE & TRUE
## [1] TRUE
TRUE & FALSE
## [1] FALSE
FALSE & FALSE
## [1] FALSE

# OR operator "|"
TRUE | TRUE
## [1] TRUE
TRUE | FALSE
## [1] TRUE
FALSE | FALSE
## [1] FALSE

# Both operators are useful for checking for ranges of data
y
## [1] 0 3 1 5 2
index1 <- (y <= 3) & (y > 0)
y[index1]
## [1] 3 1 2
index2 <- (y < 2) | (y > 4)
y[index2]
## [1] 0 1 5

# In an example
summary(iris[iris$Sepal.Width > 3 & iris$Sepal.Width < 3.5, ])
##   Sepal.Length    Sepal.Width     Petal.Length    Petal.Width          Species
##  Min.   :4.400   Min.   :3.100   Min.   :1.200   Min.   :0.100   setosa    :20
##  1st Qu.:4.925   1st Qu.:3.125   1st Qu.:1.500   1st Qu.:0.200   versicolor: 8
##  Median :5.950   Median :3.200   Median :4.450   Median :1.400   virginica :14
##  Mean   :5.781   Mean   :3.245   Mean   :3.460   Mean   :1.145
##  3rd Qu.:6.700   3rd Qu.:3.400   3rd Qu.:5.375   3rd Qu.:2.075
##  Max.   :7.200   Max.   :3.400   Max.   :6.000   Max.   :2.500

Exercise C.8 Do the following for the iris dataset:

  • Compute the subset corresponding to Petal.Length either smaller than 1.5 or larger than 2. Save this dataset as irisPetal.
  • Compute and summarize a linear regression of Sepal.Width into Petal.Width + Petal.Length for the dataset irisPetal. What is the \(R^2\)? Solution: 0.101.
  • Check that the previous model is the same as regressing Sepal.Width into Petal.Width + Petal.Length for the dataset iris with the appropriate subset expression.
  • Compute the variance for Petal.Width when Petal.Width is smaller or equal that 1.5 and larger than 0.3. Solution: 0.1266541.

Plotting functions

# "plot" is the main function for plotting in R
# It has a different behavior depending on the kind of object that it receives

# How to plot some data
plot(iris$Sepal.Length, iris$Sepal.Width, main = "Sepal.Length vs Sepal.Width")


# Alternatively
plot(iris[, 1:2], main = "Sepal.Length vs Sepal.Width")


# Change the axis limits
plot(iris$Sepal.Length, iris$Sepal.Width, xlim = c(0, 10), ylim = c(0, 10))


# How to plot a curve (a parabola)
x <- seq(-1, 1, l = 50)
y <- x^2
plot(x, y)

plot(x, y, main = "A dotted parabola")

plot(x, y, main = "A parabola", type = "l")

plot(x, y, main = "A red and thick parabola", type = "l", col = "red", lwd = 3)


# Plotting a more complicated curve between -pi and pi
x <- seq(-pi, pi, l = 50)
y <- (2 + sin(10 * x)) * x^2
plot(x, y, type = "l") # Kind of rough...


# Remember that we are joining points for creating a curve!
# More detailed plot
x <- seq(-pi, pi, l = 500)
y <- (2 + sin(10 * x)) * x^2
plot(x, y, type = "l")


# For more options in the plot customization see
?plot
## Help on topic 'plot' was found in the following packages:
##
##   Package               Library
##   base                  /Library/Frameworks/R.framework/Resources/library
##   graphics              /Library/Frameworks/R.framework/Versions/4.1-arm64/Resources/library
##
##
## Using the first match ...
?par

# "plot" is a first level plotting function. That means that whenever is called,
# it creates a new plot. If we want to add information to an existing plot, we
# have to use a second level plotting function such as "points", "lines" or "abline"

plot(x, y) # Create a plot
lines(x, x^2, col = "red") # Add lines
points(x, y + 10, col = "blue") # Add points
abline(a = 5, b = 1, col = "orange", lwd = 2) # Add a straight line y = a + b * x

Exercise C.9 Do the following:

  • Plot the faithful dataset.
  • Add the straight line \(y=110-15x\) (red).
  • Make a new plot for the function \(y=\sin(x)\) (black). Add \(y=\sin(2x)\) (red), \(y=\sin(3x)\) (blue), and \(y=\sin(4x)\) (orange).

Distributions

# R allows to sample [r], compute density/probability mass functions [d],
# compute distribution function [p], and compute quantiles [q] for several
# continuous and discrete distributions. The format employed is [rdpq]name,
# where name stands for:
# - norm -> Normal
# - unif -> Uniform
# - exp -> Exponential
# - t -> Student's t
# - f -> Snedecor's F
# - chisq -> Chi squared
# - pois -> Poisson
# - binom -> Binomial
# More distributions:
?Distributions

# Sampling from a Normal - 5 random points from a N(0, 1)
rnorm(n = 5, mean = 0, sd = 1)
## [1] -1.12055305 -0.06232391  0.71414179  0.77304492  1.98370559

# If you want to have always the same result, set the seed of the random number
# generator
set.seed(45678)
rnorm(n = 5, mean = 0, sd = 1)
## [1]  1.4404800 -0.7195761  0.6709784 -0.4219485  0.3782196

# Plotting the density of a N(0, 1) - the Gauss bell
x <- seq(-4, 4, l = 100)
y <- dnorm(x = x, mean = 0, sd = 1)
plot(x, y, type = "l")


# Plotting the distribution function of a N(0, 1)
x <- seq(-4, 4, l = 100)
y <- pnorm(q = x, mean = 0, sd = 1)
plot(x, y, type = "l")


# Computing the 95% quantile for a N(0, 1)
qnorm(p = 0.95, mean = 0, sd = 1)
## [1] 1.644854

# All distributions have the same syntax: rname(n,...), dname(x,...), dname(p,...)
# and qname(p,...), but the parameters in ... change. Look them in ?Distributions
# For example, here is the same for the uniform distribution

# Sampling from a U(0, 1)
set.seed(45678)
runif(n = 5, min = 0, max = 1)
## [1] 0.9251342 0.3339988 0.2358930 0.3366312 0.7488829

# Plotting the density of a U(0, 1)
x <- seq(-2, 2, l = 100)
y <- dunif(x = x, min = 0, max = 1)
plot(x, y, type = "l")


# Computing the 95% quantile for a U(0, 1)
qunif(p = 0.95, min = 0, max = 1)
## [1] 0.95

# Sampling from a Bi(10, 0.5)
set.seed(45678)
samp <- rbinom(n = 200, size = 10, prob = 0.5)
table(samp) / 200
## samp
##     1     2     3     4     5     6     7     8     9
## 0.010 0.060 0.115 0.220 0.210 0.215 0.115 0.045 0.010

# Plotting the probability mass of a Bi(10, 0.5)
x <- 0:10
y <- dbinom(x = x, size = 10, prob = 0.5)
plot(x, y, type = "h") # Vertical bars


# Plotting the distribution function of a Bi(10, 0.5)
x <- 0:10
y <- pbinom(q = x, size = 10, prob = 0.5)
plot(x, y, type = "h")

Exercise C.10 Do the following:

  • Compute the \(90\%,\) \(95\%\) and \(99\%\) quantiles of a \(F\) distribution with df1 = 1 and df2 = 5. Answer: c(4.060420, 6.607891, 16.258177).
  • Plot the distribution function of a \(U(0,1).\) Does it make sense with its density function?
  • Sample \(100\) points from a Poisson with lambda = 5.
  • Sample \(100\) points from a \(U(-1,1)\) and compute its mean.
  • Plot the density of a \(t\) distribution with df = 1 (use a sequence spanning from -4 to 4). Add lines of different colors with the densities for df = 5, df = 10, df = 50 and df = 100. Do you see any pattern?

Functions

# A function is a way of encapsulating a block of code so it can be reused easily
# They are useful for simplifying repetitive tasks and organize the analysis

# This is a silly function that takes x and y and returns its sum
# Note the use of "return" to indicate what should be returned
add <- function(x, y) {
  z <- x + y
  return(z)
}

# Calling add - you need to run the definition of the function first!
add(x = 1, y = 2)
## [1] 3
add(1, 1) # Arguments names can be omitted
## [1] 2

# A more complex function: computes a linear model and its posterior summary.
# Saves us a few keystrokes when computing a lm and a summary
lmSummary <- function(formula, data) {
  model <- lm(formula = formula, data = data)
  summary(model)
}
# If no return(), the function returns the value of the last expression

# Usage
lmSummary(Sepal.Length ~ Petal.Width, iris)
##
## Call:
## lm(formula = formula, data = data)
##
## Residuals:
##      Min       1Q   Median       3Q      Max
## -1.38822 -0.29358 -0.04393  0.26429  1.34521
##
## Coefficients:
##             Estimate Std. Error t value Pr(>|t|)
## (Intercept)  4.77763    0.07293   65.51   <2e-16 ***
## Petal.Width  0.88858    0.05137   17.30   <2e-16 ***
## ---
## Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## Residual standard error: 0.478 on 148 degrees of freedom
## Multiple R-squared:  0.669,  Adjusted R-squared:  0.6668
## F-statistic: 299.2 on 1 and 148 DF,  p-value: < 2.2e-16

# Recall: there is no variable called model in the workspace.
# The function works on its own workspace!
model
## Error in eval(expr, envir, enclos): object 'model' not found

# Add a line to a plot
addLine <- function(x, beta0, beta1) {
  lines(x, beta0 + beta1 * x, lwd = 2, col = 2)
}

# Usage
plot(x, y)
addLine(x, beta0 = 0.1, beta1 = 0)


# The function "sapply" allows to sequentially apply a function
sapply(1:5, sqrt)
## [1] 1.000000 1.414214 1.732051 2.000000 2.236068
sqrt(1:5) # The same
## [1] 1.000000 1.414214 1.732051 2.000000 2.236068

# The advantage of "sapply" is that you can use with any function
myFun <- function(x) c(x, x^2)
sapply(1:5, myFun) # Returns a 2 x 5 matrix
##      [,1] [,2] [,3] [,4] [,5]
## [1,]    1    2    3    4    5
## [2,]    1    4    9   16   25

# "sapply" is useful for plotting non-vectorized functions
sumSeries <- function(n) sum(1:n)
plot(1:5, sapply(1:10, sumSeries), type = "l")
## Error in xy.coords(x, y, xlabel, ylabel, log): 'x' and 'y' lengths differ

# "apply" applies iteratively a function to rows (1) or columns (2)
# of a matrix or data frame
A <- matrix(1:10, nrow = 5, ncol = 2)
A
##      [,1] [,2]
## [1,]    1    6
## [2,]    2    7
## [3,]    3    8
## [4,]    4    9
## [5,]    5   10
apply(A, 1, sum) # Applies the function by rows
## [1]  7  9 11 13 15
apply(A, 2, sum) # By columns
## [1] 15 40

# With other functions
apply(A, 1, sqrt)
##         [,1]     [,2]     [,3] [,4]     [,5]
## [1,] 1.00000 1.414214 1.732051    2 2.236068
## [2,] 2.44949 2.645751 2.828427    3 3.162278
apply(A, 2, function(x) x^2)
##      [,1] [,2]
## [1,]    1   36
## [2,]    4   49
## [3,]    9   64
## [4,]   16   81
## [5,]   25  100

Exercise C.11 Do the following:

  • Create a function that takes as argument \(n\) and returns the value of \(\sum_{i=1}^n i^2.\)
  • Create a function that takes as input the argument \(N\) and then plots the curve \((n, \sum_{i=1}^n \sqrt{i})\) for \(n=1,\ldots,N.\) Hint: use sapply.

Control structures

# The "for" statement allows to create loops that run along a given vector
# Prints 5 times a message (i varies in 1:5)
for (i in 1:5) {
  print(i)
}
## [1] 1
## [1] 2
## [1] 3
## [1] 4
## [1] 5

# Another example
a <- 0
for (i in 1:3) {
  a <- i + a
}
a
## [1] 6

# Nested loops are possible
A <- matrix(0, nrow = 2, ncol = 3)
for (i in 1:2) {
  for (j in 1:3) {
    A[i, j] <- i + j
  }
}

# The "if" statement allows to create conditional structures of the forms:
# if (condition) {
#  # Something
# } else {
#  # Something else
# }
# These structures are thought to be inside functions

# Is the number positive?
isPositive <- function(x) {
  if (x > 0) {
    print("Positive")
  } else {
    print("Not positive")
  }
}
isPositive(1)
## [1] "Positive"
isPositive(-1)
## [1] "Not positive"

# A loop can be interrupted with the "break" statement
# Stop when x is above 100
x <- 1
for (i in 1:1000) {
  x <- (x + 0.01) * x
  print(x)
  if (x > 100) {
    break
  }
}
## [1] 1.01
## [1] 1.0302
## [1] 1.071614
## [1] 1.159073
## [1] 1.35504
## [1] 1.849685
## [1] 3.439832
## [1] 11.86684
## [1] 140.9406

Exercise C.12 Do the following:

  • Compute \(\mathbf{C}_{n\times k}\) in \(\mathbf{C}_{n\times k}=\mathbf{A}_{n\times m} \mathbf{B}_{m\times k}\) from \(\mathbf{A}\) and \(\mathbf{B}.\) Use that \(c_{i,j}=\sum_{l=1}^ma_{i,l}b_{l,j}.\) Test the implementation with simple examples.
  • Create a function that samples a \(\mathcal{N}(0,1)\) and returns the first sampled point that is larger than \(4.\)
  • Create a function that simulates \(N\) samples from the distribution of \(\max(X_1,\ldots,X_n)\) where \(X_1,\ldots,X_n\) are iid \(\mathcal{U}(0,1).\)

References

R Core Team. 2017. R: A Language and Environment for Statistical Computing. Vienna, Austria: R Foundation for Statistical Computing. https://www.R-project.org/.
